Introduction to 5052 Aluminum Coil

1. Basic Information

Alloy Composition: 5052 aluminum coil is an AL-Mg alloy, containing approximately 2.5% magnesium and 0.25% chromium.
Physical Properties: It has a density of 2.73 g/cm³, a melting point range of 607-649℃, a thermal expansion coefficient of 23.8 µm/m•k (20-100℃), a conductivity of 35% IACS at 20℃, and a resistivity of 0.0493 Ωmm²/m at 20℃.
Mechanical Properties: For 5052-H32 alloy & temper, the tensile strength is 210-260 MPa, yield strength is 130 MPa, elongation is 5%, and hardness is 61 HB.

2. Product Specifications

Thickness: 0.2-8.00 mm
Width: 100-2650 mm
Length: C
ID: Ø505mm or customized
Surface: Mill finish surface, bright, polished surface, with blue PVC films or paper interleaved
Package: Eye to sky or Eye to wall
Certificate: DNV, ABS, CCS, BV

3. Product Features

Strong Plasticity: 5052 aluminum coil has strong plasticity, making it easy to process into various shapes and sizes.
Good Corrosion Resistance: It has excellent resistance to seawater, atmosphere, gasoline, and other chemicals.
Good Weldability: It can be welded using various methods, including MIG and TIG, offering reliable performance in structural applications.
Good Cold Workability: It can be cold worked to increase its hardness.

4. Applications

Marine Applications: Used for boat hulls, decks, fuel tanks, and marine storage containers due to its resistance to saltwater corrosion.
Automotive Industry: Used for vehicle body panels, truck trailers, and fuel tanks, helping improve fuel efficiency while maintaining structural integrity.
Construction and Architecture: Used for roofing, siding, and structural components in construction projects due to its weather resistance and formability.
Food and Beverage Industry: Used for food-grade applications such as storage tanks and packaging components due to its non-toxic and corrosion-resistant properties.
Industrial Equipment: Used in pressure vessels, refrigeration units, and machinery components due to its excellent strength and resistance to industrial chemicals.
Electronic and Computer Enclosures: Used for enclosures and housings in the electronics sector, providing protection while still allowing for adequate heat dissipation.

5. Advantages

Cost-Effective: Offers durability and strength, minimizing the need for frequent replacements.
Environmentally Friendly: Aluminum is recyclable, making 5052 a sustainable choice for manufacturers.
Lightweight: Reduces shipping and handling costs due to its lower weight compared to steel or other metals.
Easy Workability: Can be easily machined, welded, and bent, allowing for customization in various applications.

5052 Aluminum Coil
